Forged Screw Eye Bolt G-275.
This Forged Scrrew Bolt offers superior toughness and durability, plus good rust/corrosion resistance.
| Technical Notes | Conform to ASME B30.26. |
| Processing | Forged, Quenched & Tempered |
| Surface Finished | Hot Dipped Galvanized / Electric Galvanized |
| Tips | Working Load Limits shown are for in-line pull |
| Origin | China |
| Size (in) | Dimensions (in) | Weight (lbs) | ||||||||
| A | B | C | D | E | F | G | H | J | ||
| 1/4 × 2″ | 0.25 | 1.5 | 2 | 2.5 | 2.94 | 0.5 | 0.88 | 0.19 | 0.47 | 0.05 |
| 5/16 × 2-1/4″ | 0.31 | 1.69 | 2.25 | 2.94 | 3.5 | 0.63 | 1.13 | 0.25 | 0.56 | 0.1 |
| 3/8 × 2-1/2″ | 0.38 | 1.88 | 2.5 | 3.28 | 3.97 | 0.75 | 1.38 | 0.31 | 0.66 | 0.19 |
| 1/2 × 3-1/4″ | 0.5 | 2.44 | 3.25 | 4.25 | 5.12 | 1 | 1.75 | 0.38 | 0.91 | 0.38 |
| 5/8 × 4″ | 0.63 | 3 | 4 | 5.31 | 6.44 | 1.25 | 2.25 | 0.5 | 1.12 | 0.86 |
| 3/4 x 4-1/2″ | 0.75 | 3.5 | 4.5 | 6.25 | 7.44 | 1.5 | 2.75 | 0.62 | 1.38 | 1.38 |
